Economy Wallboard Lift

Economy Wallboard Lift







Competitively priced equivalent to the model 138-2







  • Designed to reach up to 11 feet or up to 15 feet when used with 6 foot extension
  • Easy to operate single stage winch with silent cam-lock brake
  • 5″ diameter solid rubber casters
  • Solid steel frame with dependable aircraft cable
  • Vinyl end caps help prevent material from damage during transport
  • Backstop keeps tripod assembly in place during the lifting process
  • Cradle tilts laterally 65° for installation on walls and sloped ceilings, 10° longditudinaly
  • Adjustable cradle extensions accommodate various wallboard configurations
  • Collapses for transport in most car trunks

Model:                                                   125
Weight Lifting Capacity:
150 lbs. (68 Kg)
Casters:
3 – 5″ diameter rubber tires
Mechanical System:                          Single stage winch with cam-lock brake, brass pulleys and aircraft cable
Loading Height (from floor):
37″ (94cm), 61″ (155cm) with 6′ extension or 2-4″ with model 195 Loader
Cradle Capacity:                                  Minimum 48″ (122cm), maximum 114″ (290cm)
Dimensions:                                         Caster to caster – 53″ (135cm); Cradle height from floor – 56″ (142cm)
Shipping Dimensions (LxWxH):      51 x 21 x 8″ (130 x 53½ x 20½cm)
Weight:                                                 100 lbs. (45½Kg)
Shipping Weight:
122 lbs. (55½Kg)
